3-1
3.0 ELECTRICAL INTERFACE
The electrical interface between the 4205 Tow Fish and the SeaSPY or the G-882 is via an 8-pin Micro
Subconn connection (MCIL8F/MCBH8M). The RS-232 interface is setup for 9600 baud, 8 bits, 1 stop, no
parity.
Pin out specs:
Pin 1 = 27 VDC
Pin 2 = Return and RS-232 Ground
Pin 3 = Side Scan Tx / Mag Rx (RS-232)
Pin 4 = Side Scan Rx / Mag Tx (RS-232)
Pin 5= Return and RS-232 Ground
Power Specs:
Max Power: 2 Amp @ 27 VDC ± 4%
