Section 11: Specifications
Power output with limited distortion: L/R (treble): 12W+12W
L/R (mid-range and bass): 50W + 50W
Signal to noise ratio dB(A): ≥94 dB(A)
Noise level: ≤25dB(A)
Input sensitivity: Balance input: 700±50mV
Auxiliary input: 600±50mV
Bluetooth input: 350±50mFFs
Optical input: 350±50mFFs
Coaxial input: 350±50 mFFs
Rated sound frequency response range: 48Hz~20KHz
Audio input: Balance/Auxiliary/Optical/Coaxial/Bluetooth
Tweeter unit: Planar diaphragm tweeters
Mid-range and bass driver: 5.5 inch (148mm)
Section 12: Troubleshooting
Check if the power indicator light is ON
Try to turn up the volume using either the master
volume control or remote control.
Ensure the audio cables are firmly connected and
the input is set correctly on the speakers.
Check if there is signal output from the audio
source.
Cannot connect via Bluetooth
Make sure the speaker is switched to Bluetooth
input, in other audio input mode Bluetooth can
not be paired or connected.
Disconnect from any Bluetooth device by press
and hold the volume dial in Bluetooth mode, then
try again.
Effective Bluetooth transmission range is 10
meters, please make sure operation is within the
range.
Try another Bluetooth device for connection.
The S2000DB Pro does not turn on
Check if mains power is connected. or if the wall
outlet is switched on.
