EDIFIER TWS5 User Manual

When the green lights are all lit, the charging case can charge headphones three times;
When only the leftmost green light is lit, it indicates the charging case is at low battery level, please
charge it in time; the green lights will be all lit after fully charged.
Rated input: 5V 60mA(headphone)
5V 500mA(charging case)
Warning:
The rechargeable batteries that provide power for this product must be disposed properly for
recycling. Do not dispose of batteries in fire to prevent an explosion.
Power ON/OFF
1. Power on: take headphones out from the charging case, they will turn on automatically;
2. Power off: place headphones into the charging case, they will turn off automatically;
Bluetooth Connection
Two Headphones Mode
Open the charging case to take two headphones out, they will automatically turn on and make
interconnection;
Press and hold the multifunctional button of the left headphone to enter pairing state, red and
blue light flashing rapidly;
Set mobile phone to search for and connect to “EDIFIER TWS5”, after pairing is successful, blue
light will flash slowly.
One Headphone Mode
If use one headphone only, please take the left or right headphone out from the charging case, and
refer to the procedures mentioned in “Two Headphones Mode” to pair it with mobile phone.
TWS Pairing and Connection of the Left and Right Headphones

EDIFIER TWS5 Specifications

General

Continuous audio playback time	8 h
Impedance	16 Ω
Ear coupling	Intraaural
Headphone frequency	20 - 20000 Hz
Auto power off	Yes
2.5 mm connector	No
Cables included	USB
Accessories included in set	3 sizes silicone eartips
Wireless range	10 m
Bluetooth version	5.0
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
Connectivity technology	Wireless
Product color	Black
Wearing style	In-ear
Recommended usage	Calls/Music
Protection features	Moisture resistant
International Protection (IP) code	IPX5
Microphone type	Built-in
