- 6 -
ENGLISH
on the smoke outlet. It reads the smoke temperature. It regulates the ignition stage and shuts the boiler-stove down if the tempera-
ture is too high or too low.
on the combustion air intake pipe. It detects whether the combustion air and outlet smoke are circulating correctly. It returns a vol-
tage signal which may be read on the detector status display. In the event of anomaly (which may be attributed to INcorrect smoke
outlet or combustion air intake), it shuts the stove down.
near the pellet hopper. It cuts off the power supply to the gearmotor if the temperature measured is too high.
It reads the water temperature in the boiler-stove and sends the circuit board information for pump management and boiler-stove
power modulation.
measures the temperature of the water inside the thermo-stove. If the temperature is too high, it cuts off the motor’s electrical
power supply. In the event that the thermostat has been operated, it must be re-activated by acting on the reset button behind the
boiler-stove (see page. 21).
upon reaching the pressure stipulated on the plate, the system is triggered to discharge the water and consequently the water must
be topped up.
Located under the ceramic top, it allows to read the water pressure of the stove with the thermal boiler-stove running, the recom-
mended pressure is 1bar.
It sets off of the combustion of the pellets and it remains lit until the ame has been ignited.
“pushes” the smoke into the ue and draws out combustion air via a vacuum.
activates the feed screw, which allows the pellets to be transferred from the hopper to the combustion chamber.
“pushes” water toward the heating system.
“absorbs” the variations in the volume of water contained inside the thermo-stove due to the heating effect.
Aheating technician must evaluate the need to add a second tank to the existing one, depending on total amount of water in the
system.
positioned in the upper part, it allows for the “bleeding” of any air present during the loading of water inside the boiler-stove.
placed inside the lower part of the thermal boiler-stove. This is to be opened if the water inside the thermal boiler-stove must be
emptied.
