HEATING SPECIFICATIONS
Hopper capacity 15 kg
Ef!ciency 89,2 %
Available power 3,4/8,3 kW
Time between refuellings (min/max) 7,5/20 hours
Fuel consumption (min/max) 0,7/2,0 kg/h
Heatable room dimensions (min/max) * 115/230 m3
Weight including packaging (min/max) 149/174 kg
Smoke duct diameter (A male) 80 mm
Air intake duct diameter (B male) 40 mm
* The heatable room dimensions are calculated on the basis of
pellets with an lhv of at least 4300 kcal/kg and home insulation in
compliance with Italian law 10/91.
* It is also important to consider the position of the stove in the
room to be heated.
N.B.
1) bear in mind that external devices may cause interference.
2) caution: live parts. Servicing and/or inspections must be carried out by quali•ed staff.
ELECTRICAL SPECIFICATIONS
Power supply 230Vac +/- 10% 50 Hz
On/off switch yes
Average power consumption 150 W
Power consumption during ignition 400 W
Remote control frequency (optional extra) infrared
Protection on mains power supply 2A, 250 Vac 5x20 Fuse
Electronic circuit board protection 2A, 250 Vac 5x20 Fuse
SAFETY DEVICES:
THERMOCOUPLE:
On the smoke outlet. It measures the smoke temperature.
It controls the ignition, operating and shutdown stages according to
the parameters set.
AIR FLOW SENSOR:
On the intake duct. It trips when the "ow of combustion air is not
correct, therefore causing low pressure problems in the smoke
circuit.
SAFETY THERMOSTAT:
It trips if the temperature inside the stove is too high.
It stops pellet loading, thus causing the stove to go out.
