ENGLISH
INSTALLATION
Protection from heat and safe distances
All the surfaces of the building adjacent to the pro-
duct must be protected against heating.The insulation
measurements to implement depend on the type of
surface present.
Check on the chimney system’s data plate the safety
distances to be kept in the presence of combustible
materials and the type of insulating material to be
used.
The product must be installed in accordance with the following safety instructions (dimension mm):
Windo 70
Rear = 200
Sides = 300
Front = 800
Windo 100
Rear = 300
Sides = 350
Front = 1800
Windo 90
Rear = 200
Sides = 300
Front = 800
Windo 120
Rear = 100
Sides = 100
Front = 1800
