Edimax BR-6208AC V2 User Manual

67
III-3-5-1-2. WEP
WEP (Wired Equivalent Privacy) is a basic encryption type. For a higher
level of security consider using WPA encryption.
Key Length
Select 64-bit or 128-bit. 128-bit is more secure
than 64-bit.
Key Format
Choose fo ASCII any alphanumerical
character 0-9, a-z and A-Z) or Hex any
characters from 0-9, a-f and A-F).
Encryption Key
Enter your encryption key/password according
to the format you selected above. A complex,
hard-to-guess key is recommended. Check the
Hide o to hide ou passod fo eig
displayed on-screen.
Enable 802.1x
Authentication
Check the box to enable the 802.1x
authentication. A RADIUS server is required to
perform 802.1x authentication: enter the
RADIUS sees ifoatio i the eleat
fields (below).

Edimax BR-6208AC V2 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	433 Mbit/s
Cabling technology	10/100Base-T(X)
Ethernet LAN interface type	-
Ethernet LAN (RJ-45) ports	4
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Product type	Tabletop router
Product color	White
LED indicators	LAN, Power, WLAN
Certification	FCC, CE
Output current	1.5 A
Output voltage	5 V
Power source type	DC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	31 mm
Width	160 mm
Height	115 mm
Weight	170 g
