Edimax BR-6428nS V5 User Manual

5
II. Installation
1. Plug the included power adapter into the device’s 5V DC power port and
the other end into an electrical socket.
2. Ensure that the power LED is lit. If not, the device is not properly
connected.
3. Use a Wi-Fi device (e.g. computer, tablet, smartphone) to search for a Wi-Fi
network with the SSID “edimax.setup” and connect to it.
iOS 4 or Android 4 and above are required for setup on a
smartphone or tablet.

Edimax BR-6428nS V5 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	11g (11Mbps): -79 ±2dBm, 11g (54Mbps): ‐68±2dBm, 11n (20MHz, MCS7): ‐67±2dBm, 11n (40MHz, MCS7): ‐64±2dBm
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Transmit power	16 dBmW
Antennas quantity	2
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
Output current	0.4 A
Output voltage	9 V
Power source type	DC
Product type	Tabletop router
Product color	Black
Flash memory	2 MB
Certification	CE, RoHS
Internal memory	8 MB
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Firewall security	SPI Firewall, IP and MAC Address Binding, Wireless MAC Filtering
Security algorithms	WEP, WPA, WPA2, WPA2-PSK, WPS
Supported network protocols	Dynamic IP, Static IP, PPPoE, IPv4
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Number of products included	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107 mm
Width	153.8 mm
Height	25 mm
Weight	150 g
