Edimax EN-9230TX-32 User Manual

(2) Technical Specification
y Topology : Star
y Connector : RJ-45
y Standard : IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3ab 1000BaseT
y Transmission Rate : 10Mbps/20Mbps
100Mbps/200Mbps
1000Mbps/2000Mbps
y Hardware Required : IBM compatible PC with
available PCI slot
(PCI 2.2/2.1), 64-/32-bit,
66/33MHz
y IRQ Line : Assigned by system
y I/O Address : Assigned by system
y Drivers : Windows 98SE/Me/NT/2000/XP,
Netware Server 5.x,
Netware ODI for DOS,
Linux and Unix
y LEDs : 10Mbps Link/Activity
100Mbps Link/Activity
1000Mbps Link/Activity
y Temperature : 32-131℉ (0-55℃)
y Humidity : 10% to 95% (Non-condensing)
y Certification : FCC Class B, CE Mark, C-tick
y Dimension : 163 x 64 mm (EN-9230TX-64)
144 x 63 mm (EN-9230TX-32)
yWeight : 81g (EN-9230TX-64)
76g (EN-9230TX-32)
3

Edimax EN-9230TX-32 Specifications

General

Brand	Edimax
Model	EN-9230TX-32
Category	Adapter
Language	English
