EDISON Professional Party System Drum - Edison Professional Control Legend

1
MIC.IN
Microphone input
2
GT.IN
Guitar input
3
LED ON/OFF
Speaker LED lights ON/OFF
4
VOL-
Reduce volume of drum effects
5
Drum pad
Drum pad (Closed Hi-hat)
6
Drum pad
Drum pad (Ride)
7
Drum pad
Drum pad (TOM2)
8
Drum pad
Drum pad (TOM1)
9
Drum pad
Drum pad (Crash cymbal)
10
Drum pad
Drum pad (Snare drum)
11
Drum pad
Drum pad (Bass drum)
12
VOL+
Increase volume of drum effects
13
SD card port
SD card port
14
USB port
USB port
15
Aux input
Aux input (3.5mm)
16
Start/stop playback
17
MODE
Select mode playback made (AUX/Bluetooth/USB/SD/FM)
18
►►
I
Play next track/channel
19
Vol +-
Master volume controller
20
Play previous track/channel
21
Echo +-
Microphone echo effect controller
22
MIC/GT +-
Microphone/Guitar volume controller
23
STOP
Stop demo songs playback
24
Demo
Play pre-installed demo songs
25
REC
Drum effects record (Up to 800 notes）
26
DJ effects
DJ sound effect knob
27
LED display
LED display
28
Record light
REC light up red during recording
29
Play
Play record drum effects
30
DJ MODE
DJ sound effects mode select (11 modes)
31
DRUM STYLE
Modify drum effect pitch
32
GRAPHIC EQUALIZER
Make equalizer settings
