EDLUND 270 - 270 ASSEMBLY AND PARTS LIST-115 V

Please read thoroughly before operation and keep for future reference
9
M096 REV. B
QTY
PART
NUMBER
DESCRIPTION
4 S049 SCREW, #10-32 X 3/8, SS HEX HEAD
4 S059 SCREW, #6-32 X .25, SS HEX HEAD
2 S085
SCREW, #8-32 X 1/4 S/S RHM
SLOTTED
2 S098 SCREW, #10-32 X 3/8 SHCS, SS
1 S312 SWITCH, ROCKER--HI/LOW
1 S314
SCREW, KNIFE HOLDER, KH LATCH
SHOULDER
1 S316
SCREW, KNIFE HOLDER, RIGHT
SHOULDER
1 S317
SCREW, KNIFE HOLDER, LEFT
SHOULDER
1 S318 SHIM, SS, 0.005 THK
1 S318T SHIM, .015 X .335 X.438
1 S338 SPACER, ACTUATOR LEVER
2 W010 WASHER, FLAT, #10 SS
4 W018 WASHER, #10 LOCK, PLATED
4 W022 WASHER, #6 LOCK, SS
2 W023 WASHER, #8 LOCK, SS
270 ASSEMBLY AND PARTS LIST--
115V
QTY
PART
NUMBER
DESCRIPTION
1 A055 ADAPTER, DRIVE GEAR
1 A273C
WELDMENT, HOUSING
ASSEMBLY
1 A274 WELDMENT, BASE
1 A279 ASSEMBLY, GEAR SHIELD
1 A281 ASSEMBLY, SWITCH ACTUATOR
2 A2812
ASSEMBLY, LEVER ARM
BEARING MOUNT
1 A2814 ASSEMBLY, ROLLER SWITCH
1 A2815 ASSEMBLY, LEVER CAM
1 A283DC
ASSEMBLY, 270 FRAME,
MOTOR/GEAR TRAIN, 115V
1 A288 ASSEMBLY, KNIFE HOLDER
1 A586
ASSEMBLY, SPEED CONTROL
DIODES
2 A641
ASSEMBLY, CORD W/
CONNECTORS
1 B410 BREAKER, THERMAL, 1.2 A
1 G041 GEAR, CAN DRIVE
1 G047 GASKET, BASE
1 K031 KNOB, LEVER ARM
1 K045 KNIFE
1 L049 LABEL, NSF
1 L065 LEVER, ACTUATOR ARM
1 L066 LATCH, KNIFEHOLDER
1 L073
RATING LABEL, 270, POWER
MOTOR, 115V
1 L087 CAUTION LABEL, RED, 270
5 P165 PLUG
1 P244 PLATE, GASKET
1 P392 PLATE, LOUVER COVER
1 P393 PLUG
