Edwards E1M18 - Figure 6 Single-Phase Motors: 200 V 50 Hz, 200-210 V 60 Hz and 230 V 60 Hz; Figure 7: Single-Phase Motors with Amphenol Connector: 220-240 V 50 Hz and 230-240

Figure 6 Single-phase motors: 200 V 50 Hz, 200-210 V 60 Hz and 230 V 60 Hz
N
L
N
L
U1
V1
W1
VT
BN
BN
OR
GY
WH
CS/1116/A
Wire colour codes:
BN Brown VT Violet
GY Grey WH White
OR Orange
Figure 7 Single-phase motors with Amphenol connector: 220-240 V 50 Hz and 230-240 V 60 Hz
1
23
CS/1117/A
Pin codes:
1 Live
2 Neutral
3 Not used
Earth (ground)
Page 25
A34310880_T - Installaon
