Specifications
Voltage 24 VDC, continuous. Do not use control panel
AUX power outputs that are interrupted when
the panel is reset. Supply must be UL/ULC
Listed for use with fire protective signaling
systems and have a rating designation of
Regulated 24 DC or Regulated 24 FWR.
Standby current
RLCD, RLCD-R, RLCDF
RLCD-C, RLCD-CR, RLCD-CF
RLED-C, RLED-CR, RLED-CF
RLED24, RLED24R
98 mA
99 mA
28 mA
6 mA
Alarm current
RLCD, RLCD-R, RLCDF
RLCD-C, RLCD-CR, RLCD-CF
RLED-C, RLED-CR, RLED-CF
RLED24, RLED24R
113 mA
115 mA
62 mA
34 mA
Annunciator circuit
Class/Style
Wire size
Type
Length
Baud rate
Class B, Redundant Class B, or Class A
14 to 18 AWG (1.0 to 2.5 mm²)
Twisted pair, 6 twists per ft. min.
4,000 ft. (1,219 m), max.
9600 to 115200 baud
Remote key switch circuit 5 VDC at 1 mA, power-limited, unsupervised
Ground fault impedance 0 Ω
Power wiring 14 to 18 AWG (1.0 to 2.5 mm²)
Display area 4 lines of 20 characters each
Dimensions (H x W x D) 5-5/8 x 8-1/2 x 1-1/2 in. (14.3 x 21.4 x 3.8 cm)
Mounting North American 4 in. square electrical box or
listed enclosure (see Table 2)
Operating environment
Temperature
Relative humidity
32 to 120°F (0 to 49°C)
0 to 93% noncondensing
