20 R-Series Remote Annunciators and Expanders Installation and Operation Guide
Entering a password
When the Controls Enabled LED is off, you need to enter a password to enable
the controls. When you press any of the control buttons, the system displays the
Enter Password screen.
(1) Title line: This is constant text.
(2) Password: You use the Up and Down cursor buttons to scroll through the digits in each
position of the password. Each number appears on this line, but is masked as soon as you
press the Enter button.
(3) Instruction lines: These lines prompt you to press the Up and Down cursor buttons to select a
number, or the Enter button to select a number and move to the next position.
To enter a password:
1. Press any of the control buttons.
The system displays the Enter Password screen, with the cursor in the first
position of the four-digit password field.
2. Press the Up or Down cursor button to scroll through the numbers until the
correct number appears.
3. Press the Enter button to enter that number and move to the next position.
When you press Enter, the system masks the number you just entered with
an asterisk.
4. Repeat steps 2 and 3 until you’ve entered all four digits of the password.
If you make a mistake, pressing Enter before filling all four positions cancels the
operation, and returns you to the System Normal screen. If you enter an invalid
password, the system displays an error message and returns you to the Enter
Password screen.
ENTER PASSWORD
?---
SCROLL=+/-NUMBER
ENTER =NEXT DIGIT
(1
)
(2
)
(3
)
