RANDOM MODE SETTING 2 CIRCUITS
- setting of the maximum time of ON and OFF for the relay on random mode, “random”, which is
the same for both, but connected to ON separately; menu input by pushing the button; using the
cursors for choosing the wanted screen for:
- setting of the maximum time to connect to ON the relay for minutes - temporising will be in
random time from 1 to
minutes;
- setting of the maximum time to disconnect to OFF the relay for minutes - temporising will be in
random time from 1 to
minutes;
Screen
: push the button to enter; with the cursors setting of the maximum time to connect to ON (for
minutes), confirmation by pushing the
button; the screen will appear.
Screen
: push the button to enter; with the cursors setting of the maximum time to disconnect OFF (for
minutes), confirmation by pushing the button; the screen will appear.
At any moment it is possible to exit all the menu screens without saving settings by pushing the buttons
or .
MAIN RESET
To cancel the electronic timer settings (hours, dates, settings, etc.), it is necessary to maintain simultaneously
pushed the buttons ( and ) in the main menu, for 3 seconds;
All the screens will be lit;
After some time, the electronic timer will request the date and hours settings.
If it also necessary to cancel all the saved programs, you should also push the
key.
WIRING DIAGRAMS
1 circuit 2 circuits
L
N
L/N
External Input
L
N
L/N
External Input
3,5 mm
Note: The external input must be operated via a switch.
DIN TH 35 e
CIRCUIT DIAGRAMS
1 circuit 2 circuits
A1 A2
IN
IN
IN
IN
141211
A1 A2
IN
IN
IN
IN
242221 141211
DIMENSIONS MM MAXIMUM RECOMMENDED LOAD BATTERY REPLACEMENT
35,5 16,8
90
45,84
67,27
49,2
33,2
18,2
2000 W 1000 W
500 W 750 W
250 W
ATTENTION: This unit incorporates a battery containing contents
that can be harmful to the environment. Please do not throw it away
without removing the battery and putting in the porper container
for recycled batteries.
EFAPEL reserves the right to modify this document or the products contained in it without notice. If in doubt please contact
EFAPEL.
