TROUBLE SHOOTING:
PROBLEM POSSIBLE CAUSE
SOLUTIONS
Vacuum not working
1. Hopper gate not closed. 1. Slide gate to closed position.
2. Cone cover not installed. 2. Install the cone cover.
3. Hose not attached properly.
3. Clear blockage or replace.
4. Engine not running at full RPM. 4. Set throttle control to FAST if equipped.
PART LIST
Ref.# Part No. Description Q’ty
1 902-13A-14-1
Adapter
1
2 806-001 Wire hose clamp 2
3
705-001 Extension vacuum hose
1
4 707-001
Handle grip
1
5 902-13A-14-2 Handle 1
6 803-005 Locknut 2
7 801-036 Hex bolt 2
8 902-13A-14-3
Vacuum nozzle
1
