1
Chipper
Cone
Discharge
Chute
Wheel
INDEX
Features ---------------------------------------------------------------------------------------------------------------------------------------- 1
Specifications --------------------------------------------------------------------------------------------------------------------------------- 1
Safety ------------------------------------------------------------------------------------------------------------------------------------------ 2-4
Assembly --------------------------------------------------------------------------------------------------------------------------------------- 5
Operation ------------------------------------------------------------------------------------------------------------------------------------- 6-7
Transportation and Storage ------------------------------------------------------------------------------------------------------------ 7-8
Maintenance --------------------------------------------------------------------------------------------------------------------------------- 8-9
Trouble Shooting --------------------------------------------------------------------------------------------------------------------------- 10
Repair ------------------------------------------------------------------------------------------------------------------------------------------- 11
Parts Breakdown ---------------------------------------------------------------------------------------------------------------------- 12-14
Warranty --------------------------------------------------------------------------------------------------------------------------------------- 14
OPTIONAL ACCESSORY ------------------------------------------------------------------------------------------------------------ 15-16
FEATURES
Shredder Hopper Handle
Engine
Stand
Rotor
Housing
Vacuum
Inlet
SPECIFICATIONS
Engine Specifications
Engine Brand
Rato
Engine Type
OHV
Power
7HP
Displacement
212CC
Starting
Recoil
RPM
3600
Fuel Capacity
0.7Gal
Oil
10W-30 for 32°F & above
5W-30 for 25°F & below
EPA3 Approval
Yes
CARB Approval
Yes
Item
No.
MF30
Chipping
Capacity
Max.
3”
Shredder Capacity
1/2”
Chipping
Knives
2
Shredder Hammer
4 Y-hammers
Reduction
Rate
15:1
Chipper Knife
Material
High Speed Steel
Hopper Dimensions (IN)
19.3 x 13
Limb
Chute
Yes
Wheel Size (IN)
10x3
Wheel
Material
PU
Wheel Type
Solid
Net
Weight
(LB)
123
Gross
Weight
(LB)
136
Assembled
Dimension (IN)
27.5 x 27.5 x 39.4
Packing Dimension (IN)
33 x 26 x 22
