Operating voltage *) **):12 24V DC STAB (-10%, +15%)
Current **):Max. 0.40 A
Idle 0.13 A (12V DC)
0.065 A (24V DC)
Micro switches **):Max. 0.5 A 30V AC/DC resist, 10 W
Operating temperature:-20°C - +60°C
Bolt throw:20 mm (deadbolt), 10 mm (double action bolt)
Backset:55, 60, 65 mm (wooden door)
30, 35, 40, 45 mm
(narrow style)
Forend:20, 24 mm (wooden door)
24, 28 mm (narrow style)
Spindle:9 mm (8 mm with snap spindle adapter)
Connection cable: Z09KAB (10 m) 16 x 0.14 mm
2
Door clearance:2 - 5.5 mm
Settable functions:Mechanical functions:
- Opening direction of trigger bolt
- Exit handle side (709X)
Electrical function: *) **)
- Fail locked / Fail unlocked
Monitoring outputs **):Bolt deadlocked
Lock open
Trigger bolt in
Handle down
Cylinder used
Sabotage
Strike plate:Z09XSBL-01 ... Z09XSBL-04
*) Not micro switch locks
**) Not mechanical locks
TECHNICAL DETAILS
TESTED ACCORDING TO THE STANDARDS
EN 179 3 7 6 1 1 3 4 2 A Exit
EN 1125 3 7 6 1 1 3 4 1/2 A Panic exit
EN 1634-1 Fire
EN 61000-6-1:2001 EMC
EN 61000-6-3:2001 EMC
EN STANDARDS
ENGLISH
5
