Effecta AB - Västra Rågdalsvägen 21 - 434 96 Kungsbacka - 0300 - 22320 - info@effecta.se
1 Wood gasication boiler
2 Safety valve, 1,5bars
3 Laddomat valve
4 Electrical heater
5 Valve combination
6 Shunt valve with automatic motor
7 Outlet frfom safety valve
8 Suitable connection for an open expansion vessel
9 Suitable placement for air escape vent
10 Suitable connection for pressure vessel
11 Return water from the radiators
12
Domestic cold water inlet
Systemet
