The seat of this bike is fully adjustable as it
moves Up, Down, Forward and Backward.
A. To adjust the height of the Seat Post
(No.31), loosen and pull out the Knob
(No.13), then raise or lower the seat to the
desired height. Once adjusted, re-insert and
tighten the Knob (No.13) to secure the seat
in place. (Figure A)
B. To adjust the seat forward and backward,
loosen Knob (No.34), then slide the Seat
Slider (No.30) to the desired position. Once
positioned, tighten the Knob (No.34) to
secure the Seat Slider (No.30) in place.
(Figure B)
C. To adjust the height of Handlebar
(No.78), loosen and pull on the Knob
(No.13), then slide the Handlebar Post
(No.74) up or down to the desired height.
Once adjusted, tighten the Knob (No.13) to
secure the Handlebar Post (No.74) in place.
