Efitment IC035 - Hardware Package Contents

5
77
Nut M12*1*H5*S19
2
87
Meter
1
78
Handlebar
1
88
Trunk Line
1
79
End Cap Φ25*16
2
89
Sensor Wire
1
80
Foam Grip Φ23*3*420
2
90
PU Washer
1
81
Main Frame
1
91
Tension Knob Bracket
1
82
Washer d5*Φ13*1
1
92
Wave Washer d17*Φ22*0.3
1
83
Screw M5*16*Φ8
1
93
Washer d5*φ10*1.0
4
84
Pulse Sensor
2
94
Allen Wrench S6
1
85
Screw ST4.0*19*Φ11
2
95
Spanner S13*14*15
1
86
Plug Φ12*11*Φ3
2
HARDWARE PACKAGE
EXPLODED DRAWING
#9 M8*20*S6 4PCS
#10 d8 4PCS
#11 d8*Φ16*1.5 4PCS
Steps 1
Steps 2
#33 d10*Φ30*2.5 1PC
#34 M10*Φ58*32 1PC
Steps 3
#95 S13*14*15 1PC
#94 S6 1PC
#10 d8 6PCS
#11 d8*Φ16*1.5 6PCS
#76 M8*16*S6 6PCS
