EFLOW EF-Series - Report by Exception (RBX) Alarming

EF-Series Instruction Manual
Rev 2/01 2-7
Table 2-1. Power Control Defaults
Zone Parameters Default Value
Zone 1, Start Time 400
Zone 1, On 60 Min
Zone 1, Off 0 Min
Zone 2, Start Time 700
Zone 2, On 20 Min
Zone 2, Off 10 Min
Zone 3, Start Time 1700
Zone 3, On 5 Min
Zone 3, Off 15 Min
Hold Time 1 Min
2.3.5 Report By Exception (RBX) Alarming
The RBX functionality, also called Alarm Call-in, allows a communications port to be set up to enable
the EF-Series unit to spontaneously contact the host computer (in a non-polled mode) when specified
alarm conditions exist. To configure RBX, use ROCLINK to set up the desired alarms on individual
points (such as an Analog Input) for RBX; in addition, enable the RBX Mode for the flow computer’s
Comm1 port and configure the RBX Features.
