General Information
1-2 Rev 2/01
1.2 SECTION CONTENTS
This section contains the following information:
Information Section Page Number
Manual Overview 1.1 1-1
Additional Information 1.3 1-2
Product Overview 1.4 1-3
Options 1.4.1 1-6
Installation Requirements 1.5 1-7
Environmental Requirements 1.5.1 1-7
Site Requirements 1.5.2 1-8
Compliance with Hazardous Area Standards 1.5.3 1-9
Power Installation Requirements 1.5.4 1-9
Grounding Installation Requirements 1.5.5 1-10
I/O Wiring Requirements 1.5.6 1-11
Mounting 1.6 1-12
Mounting the EF-Series Unit 1.6.1 1-12
Mounting a Radio 1.6.2 1-14
Accessing the Battery Compartment 1.6.3 1-14
Power Consumption Calculation 1.7 1-15
Determining I/O Channel Power Consumption 1.7.1 1-15
Determining Auxiliary Power Consumption 1.7.2 1-16
Totaling Power Requirements 1.7.3 1-16
Solar-Powered Installations 1.7.4 1-17
Batteries 1.7.5 1-19
Startup and Operation 1.8 1-20
Startup 1.8.1 1-20
Operation 1.8.2 1-20
1.3 ADDITIONAL INFORMATION
The following manuals may be used to acquire additional information, not necessarily found in this
manual:
!
ROCLINK for Windows Configuration Software User Manual – Part Number
D301138X012
!
ROCLINK Configuration Software User Manual – Part Number D301101X012
!
ROC/FloBoss Accessories Instruction Manual – Part Number D301061X012
