EF-Series Instruction Manual
Rev 2/01 2-37
Main Specifications (Continued)
DIMENSIONS
Overall:
18.12 in. H by 13.80 in. W by 7.25 in. D
(457 mm by 350 mm by 184 mm). Height includes
top mounting flange and Sensor.
Wall Mounting:
2.81 in. W by 13.80 in. H (72 mm
by 350 mm) between mounting hole (0.38 in.
diameter) centers.
Pipestand Mounting:
Mounts on 2-inch pipe with
U-bolt mounting kit (supplied).
WEIGHT
28.5 lb (13.0 kg) nominal, including Sensor and coupler,
but excluding batteries (not supplied).
APPROVALS
Approved by CSA as W40079 controller for
hazardous locations Class I, Division 2, Groups A,
B, C, and D.
