d. Parameters and information about the PV system can be viewed on the
“monitor” page, such as real-time system and energy information:
SN and PIN of Datalogger
Using Web to Register Cont.
Troubleshooting
LED Status
Working Status
Troubleshooting
All lights solid green Communication is good
INV LED flashing
Check the connection between
the inverter and datalogger.
Communication with inverter is
not good
Net LED flashing
Net communication is not good 1. Check if GPRS/4G is registered?
2. Check SIM card status: loose,
damaged, or no signal.
Module LED is not lit
Module is abnormal
1. Push button for more than 3
seconds to restart the datalogger
2. Change out datalogger.
c. When registering the account, provide the following information:
c-1. Customers code: This is the code provided by a distributor or installer. Please contct
your distributor or installer to obtain this code.
c-2. Datalogger SN: : The serial number is attached to the datalogger shell.
c-3. Datalogger PIN: The Pin is attached to the datalogger shell below the SN.
Using Phone to Register
Using Web to Register
For additional information regarding monitoring, see section 5.0 of the user manual which
can be downloaded here: https://eg4electronics.com/downloads/

Other manuals for EG4 18KPV

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the EG4 18KPV and is the answer not in the manual?

EG4 18KPV Specifications

General IconGeneral
ModelEG4 18KPV
CategoryInverter
Rated Power18 kW
Max. AC Output Current75A
Surge Power36 kW
Number of MPPTs2
Frequency50/60 Hz
Operating Temperature-25°C to 60°C
Warranty5 years
Output Voltage120/240VAC
CommunicationRS485
CoolingFan
Weight77 lbs (35 kg)
Dimensions670 x 530 x 220 mm
