EG4 PDP-120A-240 User Manual

3
2. EG4 Load Center Components and Features
The EG4 Load Center is an out-of-the-box unit that is pre-wired for support the integration of 2
EG4 6500 Inverters and batteries for both on-grid and off-grid residential solar installations. The
pre-wired system is designed to save thousands of dollars and precious time for both installers
and homeowners on their installation.
Warning: The EG4 Load Center must only be used with inverters running in stationary
mode (Common Neutral)
The EG4 Load Center consists of the following pre-assembled DIN rail parts:
AC Bypass Assembly (AC Protection and Transfer Switch)
# of Breakers
3
Poles per Breaker
4
Current
60A
Voltage
120/240VAC
Torque (Breaker)
22.125 in-lb (2.5 Nm)
Torque (Jumper Bar Lug)
50 in-lb (5.7 Nm)
Min Wire Size 12 AWG (4 mm
2
)
Max Wire Size
2 AWG (35 mm
2
)
Wire type
Stranded or Solid
Two DC Breakers (Battery Protection and Disconnect)
# of Poles
1
Current
125A
Voltage
60VDC
Torque
50 in-lb (5.7 Nm)
Min Wire Size
8 AWG (10 mm
2
)
Max Wire Size
1/0 AWG (50 mm
2
)
Wire type
Stranded
See Diagram 1 for pinouts
Two DC Isolators (PV Disconnect)
# of Poles
4
Current
25A
Voltage
600V DC
Torque
10.62 – 15.93 in-lb (1.2–1.8 Nm)
Min Wire Size
12 AWG (4mm
2
)
Max Wire Size
6 AWG (16mm
2
)
Wire type
Stranded or Solid
