full clockwise (CW) would go 90 degrees to the right. The reality is that many servos do not
have 180 degrees of travel, so we label them by percent of travel which is ALWAYS related
directly to the standard pulse-width of the servos.
This label is the “Set” direction of the servo, i.e. the direction/skew that it will rotate when
triggered during deployment. The opposite direction/skew is the “Reset” direction, that’s what
you will normally use in the Test Menu.
Values are:
100% counter clockwise (CCW)
75% CCW
50% CCW
25% CCW
25% (CW)
50% CW
75% CW
100% CW
Important Note: If you change a channel from Igniter to Servo mode (or back), the servo
direction/skew or igniter on-time settings will NOT be changed. These settings are dependent
on the mode that you choose. You MUST click on the Submit button to change the mode,
THEN you need to go back into the Settings menu and select the proper on-time or
direction/skew. This is because web pages are written when the page is first loaded, so any
change you make to that page that’s dependent on another setting requires the page to be
reloaded.
Main Settings
The Main settings are accessed by clicking on the Change link next to the Main status. When
you click on the link, you’ll see this page.
