56V LITHIUM-ION CORDLESS CHAIN SAW — CS1610/CS1610-FC 21
DESCRIPTION
KNOW YOUR CHAIN SAW (Fig. 8)
The safe use of this product requires an understanding of the information on the tool and
in this operator’s manual, as well as knowledge of the project you are attempting. Before
using this product, familiarize yourself with all operating features and safety rules.
8
Chain Kickback Brake Handle Lock-off Button
Variable-Speed
Trigger Switch
Rear Handle
Grasping
surface
Front Handle
Battery-
Release
Button
Saw Chain
Oil-Tank CapGuide Bar
Oil-Inspection Window
Chain-Tensioning Adjust Knob
Bucking Spikes
Electric
Contacts
Chain Sheath
Side-Cover KnobSide Cover
Lubricating Hole
