EDGER ATTACHMENT — EA080012
EN
4. Remove the spring washer, plain washer 1, guide
wheel, bushing and plain washer 2 from the screw
pole (Fig. K). Check and replace them if they are worn.
5. Mount the screw pole through the depth-adjusting
guide bar rst, and then mount the plain washer 2,
bushing and new wheel, then mount the plain washer
1, spring washer and depth-adjusting knob onto the
screw pole in the sequence shown in Fig. K.
Fig. K parts description see below:
K-1 Depth Adjusting Knob K-5 Bushing
K-2 Spring Washer K-6 Plain Washer 2
K-3 Plain Washer 1 K-7 Screw Pole
K-4 Guide Wheel K-8
Depth Adjusting
Guide Bar
NOTICE: The guide wheel should be mounted with its at
ribs facing inwards (Fig. L).
Fig. L parts description see below:
L-1 Screws L-3 Debris Flap
L-2 Flat Rib L-4 Fixing Board
6. Lock the depth-adjusting knob.
REPLACING THE DEBRIS FLAP (Fig. L)
1. Stop the motor and remove the battery pack.
2. Use the hex wrench provided to loosen the two
screws.
3. Remove the screws, xing board and worn debris
ap.
4. Replace with a new debris ap and lock it with the
xing board and the two screws.
CHECKING AND REPLACING THE ANTI-WEAR
PROTECTIVE GUARD/GUIDE PLATE (Fig. M)
Check the anti-wear protective guard and the guide plate
for damage before starting the power tool. The anti-wear
protective guard must be replaced as soon as the gear
case becomes visible.
NOTICE: The gear case may be seriously damaged if you
do not replace the anti-wear protective guard as soon as the
gear case is visible.
1. Stop the motor and remove the battery pack.
2. Wear protective gloves. Rotate the blade as
necessary to expose the two screws.
3. Use the hex wrench provided to loosen the two
screws and remove them.
NOTICE: If you just need to replace the guide plate, loosen
and remove just the screw 1.
4. Replace the deformed or worn anti-wear protective
guard/guide plate.
5. Assemble the new anti-wear protective guard and
guide plate onto the gear case and lock them with
the two screws.
Fig. M parts description see below:
M-1 Screw 1 M-4 Anti-wear Protective Guard
M-2 Guide Plate M-5 Mounting Holes
M-3 Screw 2 M-6 Gear Case
REMOVING THE GUIDE PLATE
If you are experienced with this type of edger, or if you
nd that the guide plate is a hindrance in your edging
operation, you may remove the guide plate.
1. Loosen and remove screw 1.
2. Remove the guide plate.
3. Replace and tighten screw 1.
TRANSMISSION GEARS LUBRICATION
The transmission gears in the gear case need be
lubricated periodically with gear grease. Check the gear
case grease level about every 50 hours of operation by
removing the sealing screw on the side of the case.
If no grease can be seen on the sides of the gear, follow
the steps below to ll with gear grease up to 3/4 capacity.
Do not completely ll the transmission gears.
1. Position the edger upright so that the sealing screw
is facing upwards (Fig. N).
2. Use the multi-functional wrench provided to loosen
and remove the sealing screw. Use a grease syringe
(not included) to inject some grease into the screw
hole; do not exceed 3/4 capacity.
3. Tighten the sealing screw after injection.
STORING THE UNIT
◾ Remove the battery pack from the edger
◾ Clean the tool thoroughly before storing it.
◾ If the edger attachment is removed from the power head
and stored separately, t the end cap on the attachment
shaft to avoid dirt getting into the coupler.
◾ Store the unit in a dry, well-ventilated area, locked-up or
up high, out of the reach of children. Do not store the unit
on or adjacent to fertilizers, gasoline, or other chemicals.
Protecting the environment
Do not dispose of electrical equipment,
used battery and charger into household
waste! Take this product to an authorized
recycler and make it available for separate
collection. Electric machines must be
returned to an environmentally compatible
recycling facility.
