56 VOLT LITHIUM-ION CORDLESS MOWER — LM2130E-SP
7
EN
14. Battery Cover
15. Rear Handle
16. Rear Discharge Door
17. Side Rail
18. Mower-Status Indicator
19. Switch Lever
20. Handle
21. Support for Upright Storage
22. Trailing Shield
23. Battery-Release Button
24. Safety Key
OPERATION
ASSEMBLING THE GRASS BAG
1) Slide the grass bag onto the frame (Fig. B).
2) Assemble the top clips to the frame (Fig. C), then
assemble the two side clips. Assemble the bottom
clip last.
3) The completely assembled grass bag is shown in
Fig. D.
NOTICE: Under normal usage, bag material is subject to
wear. To reduce the risk of injury, frequently inspect the
bag assembly and replace if there are any signs of wear
or deterioration. Use only grass bags manufactured for
this mower.
ADJUSTING THE FOLDABLE HANDLE
WARNING: Do not attempt to start the mower until
the handle has been locked at one of the three preset
operating positions (UPPER OPERATING POSITION, MIDDLE
OPERATING POSITION and LOWER OPERATING POSITION).
Your mower is shipped with the handle in the compact,
LOCKED STORAGE POSITION (Fig. E).
1) Press and hold the quick-adjust lever to release the
handle from the LOCKED STORAGE POSITION.
2) Lift the handle from its folded position, then release
the lever. Gently pivot the handle upward until you hear
and feel the lock pin engage in one of the following
different positions as shown in the Fig. F.
F-1 Grass Bag Attachment/
Removal Position
F-2 Locked Storage
Position
F-3 Upper Operating
Position
F-4 Middle Operating
Position
F-5 Lower Operating
Position
SPECIFICATIONS
Voltage
56 V
No-load Speed 2700 RPM
Cutting Height
25mm/35mm/43mm/
53mm/66mm/79mm/
92mm/105mm
Cutting Height Positions 8
Cutting Width 52 cm
Grass Bag Volume 70L
Mower Weight (Without bat-
tery pack and grass bag)
25.1 kg
Blade Model AB2102D-E
Operating Temperature 0°C-40°C
Storage Temperature -20°C-70°C
Blade Brake YES
Measured sound power
level L
WA
89.8 dB(A)
K=3.35 dB(A)
Sound pressure level at
operator’s ear L
PA
80.3 dB(A)
K=3 dB(A)
Guaranteed sound
power level L
WA
(measured
according to 2000/14/EC)
93 dB(A)
Valuation of vibration a
h
:
Left
handle
0.61 m/s
2
K=1.5 m/s
2
Right
handle
0.54 m/s
2
K=1.5 m/s
2
PACKING LIST(FIG. A1)
DESCRIPTION
KNOW YOUR MOWER (Fig. A1)
1. Self-Propel Switch
2. Self-Propel Speed-Control Knob
3. Safety Button
4. Switch Button for LED Headlights
5. Handle-Locking Clamp
6. Grass Bag
7. Quick-Adjust Lever
8. Cutting-height Adjustment Lever
9. Rear Wheel
10. Front Wheel
11. Mower Deck
12. Front Handle
13. LED Headlights
