56 ZERO TURN RIDE-ON MOWER — ZT4200E-S
EN
Guaranteed sound power level
L
WA
(measured according to
2000/14/EC)
100 dB(A)
Vibration a
h
Hand
1.221 m/s
2
K=1.5 m/s
2
Body
0.568 m/s
2
K=1.5 m/s
2
◾ The declared vibration total value has been measured
in accordance with a standard test method and may
be used for comparing one tool with another;
◾ The declared vibration total value may also be used in a
preliminary assessment of exposure.
NOTICE: The vibration emission during actual use of the
power tool can differ from the declared value in which the tool
is used; In order to protect the operator, user should wear
gloves and ear protectors in the actual conditions of use.
RECOMMENDED ACCESSORIES
WARNING: Use only identical replacement parts listed
below. Use of parts that do not meet the original equipment
specifications may lead to improper performance and
compromised safety.
PART NAME MODEL NUMBER
Standard Blade AB4200
High Lift Blade AB4201
Mulching Plug AMP4200
Grass Bagger Kit ABK4200-A
Rear Bumper AMB1000
Cargo Box AMG1000
Sun Shade AMS1000
DESCRIPTION
KNOW THE MOWER (Fig. A1)
1. Seat
2. Charging Port
3. Power Unit
4. LED Rear Light
5. Storage Compartment
6. LED Sidelight
7. Rear Wheel (Drive Wheel)
8. Wash Port
9. Deck
10. Deck Protector
11. Anti-Scalp Wheel
12. Front Wheel
13. Parking-Brake Pedal
14. Daytime Running Lights
15. LED Headlights
16. Accelerator Pedal
17. Foot-Rest Area
18. Side-Discharge Chute
19. Deck-Height Adjustment Lever
20. Seat-Suspension Adjustment Knob
21. Steering Wheel
22. Right Side Box
23. Seat Position Adjustment Lever
24. PTO Switch
25. Start/Stop Button
26. Safety Key
27. Phone Storage Slot
28. Cup Holders
29. Left Paddle
30. Mower Status Indicator
31. LCD Screen
32. Right Paddle
33. Blade Speed Adjustment Button
34. CCS Button
35. Driving Mode Button
36. LED Light Switch
37. Driving Speed Adjustment Button
38. Power-unit Cover Release Button
39. Power-unit Cover
40. Power unit with six battery compartments
41. Battery-Release Button
42. Hitch
43. Attachment Mounting Cover
44. USB Port
