Ego® Page 2
Ref: EGO300-UM-1013-Rev.A
Thank you for choosing an Ego® caravan mover. This has been produced according to very high standards and has
undergone careful quality control procedures. Simply by using the remote control you can move your caravan effortlessly
into any position required within operating guidelines.
Before proceeding with installation and starting to use the mover, please read this manual very carefully and be aware of
all the safety instructions! The owner of the caravan will always be responsible for correct use. Keep this manual inside
your caravan for future reference.
The caravan mover consists of two 12V motor-powered rollers, a 12V electronic control box and a remote control. To
function, the motor-powered rollers must be engaged against the tyres of your caravan. The optional cross actuation
device enables you to engage both rollers at the same time from one side of your caravan. Once this is done the mover
is ready for operation. The remote control will allow you to move your caravan in any direction.
The chassis clamps provided are suitable for tment onto most standard caravan chassis that have an L-shape or
U-shape prole. Please refer to Fig.4 & Fig.6 for reference on dimensions and clearances BEFORE you proceed any
further with installation. If your chassis has different dimensions to those shown in Fig.4 then various chassis clamp
adapters are available to suit the majority of UK and Continental caravans; please refer to the section entitled ‘Optional
Fitting Adapters’.
* Average Current Consumption readings when using an approx. 1100Kg single axle caravan on a hard, level surface.
* Maximum Current Consumption readings when using an approx. 1100Kg single axle caravan ascending a 1:4 (25%)
gradient.
These symbols identiy important safety precautions.
They mean CAUTION! WARNING! SAFETY FIRST! IMPORTANT INFORMATION!
Specications
Installation Safety Guidelines
Important Safety Instructions
Read this User Manual carefully before installation and use. Failure to comply with
these rules could result in serious injury or damage to property.
Introduction
Fitting Guidelines
Model Number EGO300
Operational Voltage 12 Volt DC
Average Current Consumption* 19 Ampere (approx)
Maximum Current Consumption* 84 Ampere (approx)
Speed 11cm per sec. (approx)
Approx. Net Weight (inc. all xings & accessories) 40 Kg
Safe Working Load (SWL) 2250Kg
Minimum Width (caravan/trailer) 1800mm
Maximum Width (caravan/trailer) 2500mm
Power Source (battery) 12V
