Ego® Page 1
Ref: EGO300-UM-1013-Rev.A
I
Table of Contents
Package Contents (Fig.A)
Ref Qty Description Ref Qty Description
1 1 Motor Unit (B) 15 8 Chassis Clamp Washers 10mmØ
2 1 Motor Unit (A) 16 2 Chassis Stop Bolts & Nuts (2 pairs)
3 1 Cross Bar 17 4 Motor Unit Fixture Washer
4 1 Cross Bar 18 2 Motor Unit Fixture Bolt
5 1 Centre Cross Bar 19 2 Motor Unit Nylock Nuts
6 1 Carry Case inc. Motor & Battery Cables 20 1 Engagement Tool
7 1 Electronic Control unit 21 1 Motor Unit Extension Cable
8 1 Remote Control Handset 22 4 Cable Ties
9 2 Wire-Lock Pins 23 2 Roller Distance 20mm Spacers
10 2 Chassis U Plate 24 2 Cross Actuation Insert Bars
11 2 Upper Chassis Clamp Plate 25 1 Cross Actuation Centre Bar
12 2 Lower Chassis Clamp Plate 26 1 User Manual (not illustrated)
13 8 Chassis Clamp Nylock Nuts M10 27 3 AAA type 1.5V Batteries (not illustrated)
14 8 Chassis Clamp Bolts - M10x55
Package Contents (Parts List) Page 1
Introduction Page 2
Fitting Guidelines Page 2
Specications Page 2
Installation Safety Guidelines Page 2,3
Installation - Mechanical Components Page 3,4
Installation - Electrical/Electronic Components Page 4
Operation Safety Guidelines Page 5
Operation - Set-Up Page 5
Operation - Detaching/Attaching the Motors Page 6
Operation - Engaging the Rollers Page 6
Operation - Motor Units Page 6
Operation - Remote Control Handset Page 7
Operation - Electronic Control Unit Page 7
Before First Use - Pairing the Handset and Control Unit(s) Page 7,8
Using Your Caravan Mover with Quattro® Technology Page 8
Operation - Getting Started Page 8
Operation - Hitching and Unhitching Page 9
Maintenance Page 9
Trouble-Shooting Page 9,10
To Next Page
