7. Reverse the battery box to cut off the zip tie and disconnect the long yellow plug (Fig.1).
8. Take the PCBA from the battery box and remove the 4 screws to separate the electric
contact base from the battery box (Fig.2).
20
3. Main PCBA Replacement
Zip tie
Long yellow plug
1 2
LM2020E-SP Lawn Mower
