56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2100SP/LM2100SP-FC/LM2100/LM2100-FC 21
3. UPPER OPERATING POSITION: Lift
the handle with your left hand.
Gently pivot the handle backward
until you hear and feel the lock
pin engage in the Upper Operating
Position. Fully extend the side rails
and securely close the two handle-
locking clamps (Fig. 7 & 8). Taller
users may prefer this position.
4. MIDDLE OPERATING POSITION:
Press and hold the quick-adjust
lever with your left hand to release
the handle from the upper operating
position. Begin to lower the handle
with your right hand, and then
release the lever. Gently pivot the
handle downward until you hear
and feel the lock pin engage in the
Middle Operating Position. Fully
extend the side rails and securely
close the two handle-locking
clamps (Fig. 7 & 8).
5. LOWER OPERATING POSITION: Press
and hold the quick-adjust lever with
your left hand to release the handle from the middle operating position. Begin
to lower the handle with your right hand, and then release the lever. Gently pivot
the handle downward until you hear and feel the lock pin engage in the Lower
Operating Position. Fully extend the side rails and securely close the two handle-
locking clamps (Fig. 7 & 8).
NOTE: The motor cannot be started unless:
a) The side rails are fully extended
b) Both green handle-locking clamps are securely closed
c) The handle is locked into one of the three operating positions.
Indication
Line
8
7
