56-VOLT LITHIUM-ION CORDLESS 22” LAWN MOWER — LM2200SP/LM2200SP-FC30
To start the mower (Fig. 10a & 10b)
1. Attach the battery pack to the mower and close the battery compartment cover.
2. Press the power button to illuminate the dashboard, and the mower status
indicator – the blade speed indicator for mode 2 will light up.
3. Press the blade speed mode button to select the desired speed, refer to the
section "Selecting Blade Speed Mode" in this manual.
4. Press and hold the power button.
5. With the power button pressed, pull the bail switch to meet the handle. The
mower will start.
6. Release the power button.
a
b
c
10a
10b
