56V LITHIUM-ION CORDLESS 12" STRING TRIMMER22
LINE REPLACEMENT
WARNING:
Always use EGO AL0800 or AL0801 0.080 in. (2mm) replacement
nylon cutting line. Using line other than that specied may cause the string trimmer to
overheat or become damaged.
WARNING:
Never use metal-reinforced line, wire, or rope, etc. These can break
off and become dangerous projectiles.
There are two methods to replace the cutting line:
1. Wind the spool with new line.
2. Install a pre-wound spool.
Wind the spool with new line
WARNING:
To prevent serious personal injury, remove the battery pack
from the tool before servicing, cleaning,
changing attachments or removing
material from the unit.
1. Press the release tabs on the spool
retainer and remove the spool
retainer by pulling it straight out
(Fig. 16).
2. Remove the spool. Use a clean cloth
to clean the inner surface of the
spool base.
NOTICE: Always clean the spool and spool
base before reassembling the bump head.
3. Check the spool retainer, spool and
spool base for wear. If necessary,
replace the wear parts.
4. Take approximately 16 ft (5m) of
new cutting line. Fold the line in half
and then adjust it so that one end
is 4 in. (10cm) longer than the other
(Fig.17).
17
4" (10 cm)
16
Tab
Tab
