EGO ST1400E-ST - Page 2

B1 B2
C2C1
LOW
1. Rear Handle
4. Hinge
2. High/low-speed Switch
3. Adjustable Front-Assist Handle
5. Line-Loading Button
6. Guard
11. Trimmer Head (Bump Head)
17. Electric Contacts
A
7. Lock Pole
8. Height
Locking Collar
9. Switch Trigger
10. Locking Tongue
15. Battery
Release Button
16. Latch
12. Line
Cutting Blade
13. Release
Tab
14. Cutting Line
18. Ejection
Mechanism
19. Hex Wrench
