EGO ST1500F User Manual

56-VOLT LITHIUM-ION CORDLESS 15" STRING TRIMMER28
6. Remove the flange from the spool
base and save it to secure the new
spool base (Fig. 27).
Install the new trimmer head
1. Position the flange removed in step
6 of the “remove the trimmer head”
section onto the motor shaft with
the flat surface facing away from
the base (Fig. 28).
2. Align the mounting hole in the
spool base with the motor shaft and
mount the base onto the shaft.
3. Position the plain washer and then
the spring washer onto the motor shaft (Fig. 29).
27
Flange
28
Flat surface facing
away from the base
Spool Base
29
Plain Washer
Plain Washer
Spring Washer
