56-VOLT LITHIUM-ION CORDLESS 15" STRING TRIMMER—ST1520 & ST1520S 23
3. Insert the line into the eyelet (Fig.15)
and push the line until the end of
the line comes out of the opposite
eyelet.
NOTICE: It is not necessary to align the
eyelets in order to insert the cutting line. If
the line cannot be inserted into the eyelet,
mount the battery pack onto the trimmer,
then press the line-loading button briey
to release the lower cover.
4. Remove the battery if it has been
mounted onto the trimmer in step 3.
5. Pull the line from the other side until
equal lengths of the line appear on
both sides of the trimmer head
(Fig. 16).
6. Install the battery pack onto the
string trimmer.
7. Press and hold the line-loading
button to start the line-winding
motor. The line will be wound into
the trimmer head continuously
(Fig. 17).
8. Watch the remaining line length
carefully. Prepare to release the
button as soon as approximately 7
inches (17.8cm) of line are left on
each side. Briey press the line-
loading button to adjust the length until 5.5 inches (14cm) of the line is showing
on each side.
9. Push down on the trimmer head while pulling on the lines to manually advance
the line in order to check for proper assembly of the cutting line.
NOTICE: In case the line is pulled into the trimmer head by accident, open the head
and pull the cutting line out from the spool. Follow the section “RELOAD THE CUTTING
LINE” in this manual to reload the line.
16
Isometric Cutting Line
17
5.5" (14cm)
15
Eyelet
Cutting Line
Lower Cover
To Next Page
