STRING TRIMMER ATTACHMENT—STA150014
MOUNTING THE GUARD
NOTICE: Install the guard before the attachment is connected to the power head.
WARNING:
To reduce the risk of injury to persons, do not operate without guards
in place.
WARNING:
Always wear gloves
when mounting or replacing the guard.
Be careful of the blade on the guard and
protect your hands from being injured by
the blade.
1. Lift the trimmer head and face it
downward; align the two mounting
holes in the guard with the two bolts
that are preassembled on the base
of the shaft. Make sure that the
internal surface of the guard faces
towards the trimmer head (Fig. 2).
2. Use the supplied hex wrench to lock
the guard in place with the bolts
(Fig. 3).
2
3
