© 2016 - 2017, Euro Games Technology Ltd. 35
HARDWARE
Power Distributor Units
EGT Distribution Box 220V - supplies input voltage to Main Power
Supply Units (PSU);
Distributor 12V & 24 V - supplies input voltage to decorative lighting,
gaming platform, monitors, cabinet fans and OLED keyboard.
IV.2.4. Technical Parameters
IV.3.1. Location in the Machine: Pos. 29 in Fig. IV.2.
IV.3.2. Type: Exciter II
Gaming platform Exciter II consists of:
Exciter II Mother Board - MB-EG780
Connectors Board - IP-EG915
Intermediate Board - ID-EG780
IV.3.3. Purpose of Use
Exciter II is the managing computer (platform) in a gaming machine.
Exciter II Motherboard has one main connector, through which it is
connected to the Exciter II Connectors Board.
Compact Flash Card, where are the operating system (OS) and the game
software, has to be inserted into connector SATA1.
BIOS Memory and NVRAM back-up battery is located on the Exciter II
Mother Board. There are 4 DIP switches as the 4-th (1
-st
pin) of them is used for
machine memory reset.
Main Power Supply Unit (PSU)
Parameter Value
Input Voltages
100 ÷ 240V AC 50 ÷ 60 Hz
Rated output voltage and current
Mean Well HRP-300-12 or COSEL PLA300F-12
12V DC 25A
Power Distribution Unit (PDU) 220 V
Fuses: F1 and F2 are the main fuses of the gaming machine
Distributor 12V & 24V
IV.3. EXCITER II - SPECIALIZED GAMING PLATFORM
HARDWARE COMPONENTS
