11
ICON EXPLANATION
INSTALLATION
3
1
Left
Put the aircraft upside down on soft surface to avoid scratches.
Right
LOCK: Tighten the propeller in this direction.
UNLOCK: Remove the propeller in this direction.
Attach the black nut propellers to the R motors in the same way.
2
Match the red nut propellers with the L motors, and tighten the propellers according
to the fastening instructions.
To Next Page
