SSR Operating Instructions
6/10
Vers. 2.4 © ehb errors excepted
-
For switching, the output transistors require a release from the processor and voltage
at input 50e (redundancy).
Assembly
-
Assembly is visible in the engine compartment
-
Use short cables from the ignition start switch and to the starter
-
Protect the SSR from exposure to water and dirt
-
Assemble in a low-vibration location
-
Assemble with the connector side facing downwards
-
Provide sufficient spacing for the connector and cables
Technical Data
Electrical data:
Mechanical data:
Test standard
Voltage range
•
9-36V (typical 12 V to 24 V)
•
No current flow at the outputs with reversed supply
voltage
Power consumption
1 mA at retirement
Securing
Protection against permanent reverse polarity of the
supply voltage
Operating temperature
-20 bis +70 °C
Storage temperature
-30°C to +80°C
Inputs
•
PIN 03 | terminal W
•
PIN 05 | Starter, terminal 50e
Outputs
All outputs short-circuit proof
• PIN 06 | Starter, terminal 50f, 25 A Short circuit cur-
rent limitation 65-180 A
• PIN 02 | D+, 2 A
Housing dimensions (L x H x D)
61 x 31 x 60 mm
Mounting dimensions (L x W x
H)
71 x 95,5 x 35,4 mm
Panel cut-out (W x H)
Twice
6,4 x 8,3mm
Housing material
PA6.6
Weight
78g
Installation
2 x M6 Screws
Degree of protection:
IP 53 / Connection plugs must point downwards
Connection
Plug 8 pin, AMP Positive Lock
