Refer to “Engine Technical Specification” for Qty of Coolant Required for the respective Engine
CAUTION! :
Be sure to use EICHER Genuine Coolant
Never Mix it with any other coolant, anti-freezes or anti rusts.
Ensure that the caps of the radiator assembly and that of coolant are tightened.
BELT TENSION CHECKING AND ADJUSTMENT:
As shown in figure, press the V belt and check whether
there is a deflection of 10-15 mm.
In case the deflection is less or more than the above value
then loosen two bolts of alternator which is shown in the
figure with arrows.
With the help of a long rod move the
alternator assembly in required direction and
retighten the two bolts.
