8
ENGINE ORIENTATION AND PARTS ILLUSTRATION (EE483TCI -TURBO CHARGED INTERCOOLED ENGINE):
1
2
3
4
5
6
7
8
1
Hose
-
Air Filter to Pipe TC in B
5
Intercooler Assy
2
Pipe TC in B
6
Hose
–
Thermostat to Radiator
3
Hose
-
Intercooler Outlet
7
Pipe
-
Turbo
Charger to Intercooler inlet
4
Pipe TC in A
8
Hose
-
Pipe Intercooler inlet to Intercooler in
