Komponenten / Ersatzteile
Position Artikel-Nr. Beschreibung
Position Artikel-Nr. Beschreibung
44 340102501144 woodruff key
46 340102501146 air camshaft
56 340102501157 washer of oil drain bolt
57 340102501158 oil drain bolt M10x15
63 340102501166 BRAKE ASSY
64 340102501167 bolt M6x12
65 340102501168 chock switch
66 340102501171 gasket of carburetor B
67 340102501172 insulating mat of carburetor
68 340102501237 gasket of caburetor A
69 340102501173 CARBURETOR assy.
70 340102501174 rubber gasket of carburetor
73 340102501178 nut M6
76 340102501183 SPRING of ignition switch
77 340102501184 THROTTLE SPRING
80 340102501187 THROTTLE CONTROLler
81 340102501188 air chock rod
82 340102501192 throttle control spring
87 340102501198 fuel tank bracket
89 340102501200 fuel tank
90 340102501204 cushion blocking of fuel tank
92 340102501206 fuel tank bolt M8x55
93 340102501207 CLIP of fuel pipe A (big)
94 340102501240 clip of fuel pipe B (small)
95 340102501208 fuel pipe A (long)
96 340102501226 fuel filter
98 340102501211 MUFFLE PAD
101 340102501213 nut for muffler
102 340102501214 STARTER BOLT
103 340102501216 STARTER
104 340102501219 starter cover
107 340102501221 starting wheel
108 340102501222 cooling fan
109 340102501225 FLYWHEEL
111 340102501224 ignitor coil
113 340102501242 fuel pipe B (short)
902 340102501902 piston rings
904 340102501904 ignition switch assy-
905 340102501905 down housing komplett
906 340102501906 crankcase assy. komplett
907 340102501907 cylinder head complete
910 340102501910 muffler cpl.
911 340102501911 limited speed gear assy.
912 340102501912 oil level gauge assy.
913 340102501913 air filter assy.
914 340102501914 crankshaft assy.
