6
Wear goggles
Wear ear-muffs
1. Layout
11. Miter stop
12. Parallel stop
13. Wheel guard
14. Table
15. Water trough
16. Housing
17. Thumb screw
18. Scale for miter cuts
19. Knurled screw
10. Thumb screw
11. Holder for splitter
12. ON/OFF switch
13. Switch housing
14. Power cable
15. Diamond cutting wheel
16. Outer flange
17. Side cover
18. Nut
19. Splitter
2. Technical data
Motor rating: 900 W S2 10 min
Motor speed: 2950 rpm
AC motor: 230 V ~ 50 Hz
Insulation class: Class B
Protection type: IP 20
Length of cut: unlimited
Length of jolly: unlimited
Cutting height: 41 mm
Cutting table:
- Dimensions 500 x 400 mm
- Material: Inox steel
Diamond cutting wheel ø 200 x 25.4
Noise emission values
The noise produced by this tile cutting machine
is measured in accordance with DIN EN ISO
3744; 11/95, DIN EN ISO 11201: 1996-07 ISO
7960 Annex A; 2/95.
The level of noise at the workplace may exceed
85 dB(A). In this case it is essential to take
suitable precautions to protect the user’s hearing
(wear ear muffs!).
Working mode
Idle
Sound pressure level LPA 92,0 dB(A) 66,1 dB(A)
Sound power level LWA 100,2 dB(A) 79,1 dB(A)
3. Important notes
Please read this operating manual carefully and
follow the instructions. Use the manual to familiarize
yourself with the machine, its proper use and safety
instructions.
Important!
For safety reasons it is prohibited for children, young
people under the age of 16 years and all persons
who have not read and understood the operating
instructions to use the tile cutting machine.
Portable tile cutting machine for medium tiles
Cutting performed by a diamond cutting wheel.
Jolly cuts with tilting work top up to 45 degrees.
Cutting wheel cooled with water.
Straight fence and mitre fence.
Removable trough as cooling water container.
(To remove: Pull out the trough as far as the stop
and then lift slightly to remove completely.)
4. Intended use
The FSM 820 NIRO tile cutting machine is designed
to perform cutting jobs on small and medium tiles
(floor and wall tiles made of ceramic and similar
material) which suit the machine’s size. It is intended
in particular for use by DIY enthusiasts and
craftsmen. The cutting of wood and metal is
prohibited. The machine is to be used solely for
its intended purpose. Any use other than its
intended use is a case of mis-use. The user/operator
and not the manufacturer shall be liable for any
damage or injury resulting from cases of mis-use.
Only those cutting wheels suitable for the machine
are to be used. The use of saw blades is prohibited.
For the machine to be used as intended it is also
imperative to observe the safety instructions, the
GB
