GB
- 22 -
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
Danger!
The electric power tool generates an electro-
magnetic fi eld during operation. Under certain
circumstances this fi eld may actively or passively
impede medical implants. To reduce the risk of
serious or fatal injuries, we recommend persons
with medical implants to consult their doctor and
the manufacturer of the medical implant prior to
using the equipment.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
The scarifi er is delivered unassembled. The grass
basket and the complete push bar must be as-
sembled and mounted before using the scarifi er.
Follow the operating instructions step-by-step and
use the pictures provided as a visual guide to ea-
sily assemble the machine.
Fitting the push bar brackets
(see Figs. 4 and 5)
•
Remove the star screw (Fig. 4/Item 1) and the
pressure plate (Fig. 4/Item 2)
•
Connect the push bar bracket (Fig. 4/Item 3)
to the fastening screw. Ensure that the curve
in the tube (Fig. 5/Item 1) is facing outside.
•
Now remount the pressure plate and tighten
with the star screw.
Notice! The identical tilt angle must be set for
both push bar brackets.
Fitting the lower push bar (see Fig. 6)
•
Slide the lower push bar (Fig. 6/Item 1) over
the push bar brackets. Do not forget to slide
the stress-relief clip (Fig. 6/Item 2) onto the
tube beforehand.
•
Now screw the tubes together using the
screws supplied (Fig. 6/Item 3), the plastic
sleeves (Fig. 6/Item 4) and the star screw
(Fig. 6/Item 5).
Fitting the upper push bar (see Fig. 7)
•
Position the upper push bar (Fig. 7) such that
its holes line up with the holes of the lower
bar.
•
Now screw the tubes together using the
screws supplied (Fig. 7/Item 1), the plastic
sleeves (Fig. 7/Item 2) and the star screw
(Fig. 7/Item 3).
•
Using the cable clips supplied (Fig. 8), attach
the power cable to the tubes of the push bars
so that it is possible to open and shut the
ejector flap (Fig. 9/Item A).
Notice!
Please ensure that the ejector fl ap can be opened
and closed easily!
Assembling the grass basket
(see Figs. 10 and -13)
•
Push both frame parts into each other (Fig.
10).
•
Pull the grass basket over the metal frame
(Fig. 11).
•
Pull the rubber clips over the metal frame
(Fig. 12).
•
To hang the grass basket on the scarifier you
must lift the ejector flap (Fig. 13/Item 1) with
one hand and with the other hand take hold of
the grass bag by the handle and hook it onto
the scarifier from above (Fig. 13).
Danger!
Before you ever hook the grass basket to the sca-
rifi er you must ensure that the motor is switched
off and the cutting unit is not rotating.
Adjusting the handlebar height (see Fig. 17)
Loosen the star screw (Fig. 17/Item 1) on both si-
des of the scarifi er by turning several revolutions.
Now adjust the handlebar to the desired height.
Notice!
The height of the handlebar may be adjusted
within the mark (Fig. 17/Item V) during operation.
Retighten the star screws.
Notice!
The identical tilt angle must be set on both sides.
Adjusting the scarifi er depth (see Fig. 14)
The scarifi er depth is adjusted at both front
wheels via the adjustment mechanism. For this,
pull out the adjusting screw and turn the wheel to
the left or right into one of the available positions
(0/I/II/III).
Anl_RG-SA_1433_SPK9.indb 22Anl_RG-SA_1433_SPK9.indb 22 31.03.2017 09:18:0431.03.2017 09:18:04
