EINHELL TC-AC 190/24 User Manual

GB
- 17 -
3. Proper use
The compressor is designed for generating
compressed air for tools operated by compressed
air.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains connection: ......................... 230 V ~ 50 Hz
Motor rating: ........................... 1500 W S2 15 min
Compressor speed min
-1
: ............................ 2850
Operating pressure bar: ............................max. 8
Pressure vessel capacity (in liters): ................. 24
Theoretical suction rate l/min.: ...................... 160
Output (compressed air) at 7 bar: ....60 liters/min
Output (compressed air) at 4 bar: ....76 liters/min
Sound power level L
WA
in dB: ........................... 97
K
WA
uncertainty: ........................................... 3 dB
Protection type: ............................................IP20
Weight of the unit in kg: ............... approx. 19,5 kg
Oil quantity: ............................... approx. 0.2 liters
Noise
The noise emission values were measured in ac-
cordance with EN ISO 2151.
5. Before starting the equipment
Warning!
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
•
Examine the machine for signs of transit da-
mage. Report any damage immediately to the
company which delivered the compressor.
•
The compressor should be set up near the
working consumer.
•
Avoid long air lines and long supply lines (ex-
tensions).
•
Make sure the intake air is dry and dust-free.
•
Do not set up the compressor in damp or wet
rooms.
•
The compressor may only be used in suitable
rooms (with good ventilation and an ambient
temperature from +5°C to +40°C). There must
be no dust, acids, vapors, explosive gases or
inflammable gases in the room.
•
The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor
in areas where work is conducted with spray-
ed water.
•
The oil level in the compressor pump has to
be checked before putting the equipment into
operation.
•
The equipment must be set up where it can
stand securely.
•
Supply hoses at pressures above 7 bar
should be equipped with a safety cable (e.g.
a wire rope).
6. Assembly and starting
Important!
You must fully assemble the appliance before
using it for the fi rst time.
6.1 Fitting the wheels (3)
Fit the supplied wheels as shown in Fig. 5.
6.2 Fitting the supporting feet (4)
Fit the supplied supporting feet (4) as shown in
Fig. 6.
6.3 Replacing the oil sealing plug (14)
Remove the transportation cover from the oil fi ller
opening with a screwdriver and insert the sup-
plied oil sealing plug (14) into the oil fi ller opening
(Fig. 7).
Anl_TC_AC_190_24_SPK1.indb 17Anl_TC_AC_190_24_SPK1.indb 17 06.08.14 14:4106.08.14 14:41

EINHELL TC-AC 190/24 Specifications

General

Motor power	1500 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Noise level	97 dB
Intake capacity	160 l/min
Maximum airflow	98 l/min
Minimum airflow	60 l/min
Air tank capacity	24 L
Pump motor speed (max)	2850 RPM
Maximum operating pressure	8 bar
Suitable for	Car
Product color	Black, Red
Housing material	-
Number of cylinders	1

Weight and Dimensions

Depth	547 mm
Width	235 mm
Height	543 mm
Weight	19480 g
Package weight	21100 g
